Mastering Fixation of Periprosthetic Fractures of the Femur

Comprehensive Introduction and Patho-Epidemiology

Periprosthetic fractures about a total hip arthroplasty (THA) represent one of the most formidable challenges in contemporary orthopedic surgery. By definition, these are fractures occurring in the femur or acetabulum adjacent to either the femoral or acetabular component, respectively. While these fractures can occur intraoperatively—often during the preparation of the femoral canal or the impaction of a cementless stem—the primary focus of this chapter is the postoperative fracture of the femur occurring adjacent to the femoral component. As the global population ages and the volume of primary and revision total joint arthroplasties increases exponentially, the incidence of periprosthetic femur fractures is rising in parallel. The management of these complex injuries requires a profound understanding of fracture biomechanics, arthroplasty principles, and geriatric medicine.

The pathogenesis of postoperative periprosthetic femur fractures is multifactorial, typically occurring in a compromised physiological and biomechanical environment. Major trauma accounts for a remarkably small proportion of these injuries. Instead, the vast majority occur following a low-energy mechanism, such as a fall from standing height, and up to 25% occur spontaneously without any identifiable antecedent trauma. This low-energy etiology highlights the compromised nature of the host bone. Patients with total hip arthroplasties frequently exhibit localized osteopenia of the proximal femur secondary to adaptive bone remodeling, commonly referred to as stress shielding. Furthermore, particulate wear debris from the bearing surface can incite a macrophage-mediated inflammatory response, leading to periprosthetic osteolysis and severe degradation of local bone stock. When combined with the high baseline prevalence of systemic osteoporosis in this demographic, the femur becomes highly susceptible to failure under minimal physiologic loads.

The natural history of periprosthetic femur fractures is characterized by significant morbidity and mortality, closely mirroring that of native proximal femur fractures in the elderly. Retrospective literature has consistently demonstrated a one-year mortality rate approaching 11%, with high rates of postoperative complications including venous thromboembolism, pneumonia, and delirium. Because the vast majority of these fractures require surgical management to achieve effective fracture healing and meaningful return of function, conservative management is rarely indicated. The physiological toll of prolonged immobilization in this frail patient population is often devastating.

Consequently, it is imperative that these patients are managed with a comprehensive, multidisciplinary approach. Co-management with geriatricians or hospitalists is critical for optimizing medical comorbidities, preventing delirium, and managing polypharmacy. The surgical strategy must prioritize early intervention, ideally within 48 hours of injury, to mitigate the risks of prolonged bed rest. Furthermore, the chosen surgical construct—whether it be osteosynthesis, revision arthroplasty, or a combination thereof—must be biomechanically robust enough to permit early weight-bearing and aggressive mobilization, thereby facilitating a rapid return to the patient's pre-injury baseline.

Detailed Surgical Anatomy and Biomechanics

The Vancouver Classification System

A rigorous understanding of periprosthetic surgical anatomy is inextricably linked to the Vancouver classification system, which remains the gold standard for describing and guiding the treatment of these complex injuries. Introduced by Duncan and Masri, this classification system categorizes fractures based on three critical parameters: the anatomic location of the fracture, the stability of the femoral component, and the quality of the surrounding host bone stock. Its widespread adoption is due to its simplicity, high inter- and intra-observer reliability, and its direct correlation with treatment algorithms.

Type A fractures occur in the trochanteric region and are subdivided into AG (involving the greater trochanter) and AL (involving the lesser trochanter). These fractures typically occur secondary to osteolysis or avulsion mechanisms. Type B fractures, which are the most common and arguably the most biomechanically complex, occur around or just distal to the tip of the femoral stem. The subclassification of Type B fractures is critical: Type B1 fractures occur around a radiographically and clinically stable implant; Type B2 fractures occur around a loose implant but with adequate surrounding bone stock; and Type B3 fractures occur around a loose implant in the setting of severely compromised or inadequate bone stock. Finally, Type C fractures occur well distal to the tip of a stable femoral component, essentially behaving as native diaphyseal femur fractures, though the presence of the proximal implant still dictates the proximal fixation strategy.

Accurate classification is the cornerstone of surgical success. Misclassification, particularly the failure to recognize a loose stem (mistaking a B2 for a B1), is the leading cause of catastrophic construct failure. The differentiation between B1 and B2 fractures requires meticulous radiographic analysis and often intraoperative confirmation. The surgeon must evaluate for progressive radiolucent lines at the bone-cement or bone-implant interface, component subsidence, and cement mantle fractures.

Biomechanical Considerations in the Periprosthetic Femur

The biomechanics of the periprosthetic femur are fundamentally altered compared to the native state. The insertion of a rigid metallic stem into the medullary canal creates a profound modulus mismatch between the stiff implant and the relatively elastic cortical bone. This mismatch creates a significant stress riser, particularly at the distal tip of the prosthesis, which is the most frequent site of periprosthetic fracture initiation (Vancouver Type B). The bone adjacent to the stem is often subjected to stress shielding, leading to cortical thinning and increased porosity, further diminishing its load-bearing capacity.

When designing a fixation construct, the surgeon must adhere to the principles of relative versus absolute stability. For comminuted fractures (which are common in this setting), relative stability using long bridging plates is preferred. This approach minimizes soft tissue stripping, preserves the delicate periosteal blood supply, and promotes indirect bone healing via robust callus formation. The working length of the construct must be maximized to distribute strain evenly across the fracture site, preventing premature hardware failure.

Furthermore, the presence of the intramedullary stem severely limits the options for proximal screw purchase. Traditional bicortical screw fixation is often impossible. Surgeons must rely on alternative fixation strategies, such as cerclage cables, variable-angle locking screws that can be directed around the stem, or specialized periprosthetic plates with offset screw holes. Biomechanical studies have demonstrated that insufficient overlap of the femoral prosthesis by the fixation plate is a primary driver of mechanical failure. The plate must extend proximally to the level of the greater trochanter to provide adequate leverage against varus deforming forces, and distally it should span the entire length of the femur to prevent future stress fractures at the end of the plate.

Exhaustive Indications and Contraindications

The decision-making process for managing periprosthetic femur fractures is highly nuanced, requiring a delicate balance between the patient's physiological capacity to withstand major surgery and the absolute necessity of restoring skeletal stability. Operative intervention is indicated for the vast majority of these fractures. Nonoperative management is exceedingly rare and is generally reserved for truly undisplaced Vancouver Type AL fractures, minimally displaced Type AG fractures without significant abductor compromise, or completely undisplaced Type B1 fractures in patients whose medical comorbidities preclude any form of anesthesia. Even in these select cases, conservative management involves prolonged periods of restricted weight-bearing, which carries its own substantial risks of deep vein thrombosis, decubitus ulcers, and rapid deconditioning.

Surgical indications are directly tied to the Vancouver classification. Vancouver Type B1 and Type C fractures, where the femoral component is definitively stable, are absolute indications for open reduction and internal fixation (ORIF). The goal is to bypass the fracture with a robust extramedullary construct while preserving the well-fixed arthroplasty. Conversely, Vancouver Type B2 and B3 fractures, characterized by a loose femoral component, represent absolute indications for revision arthroplasty. Attempting to fix a fracture around a loose stem is a well-documented error that invariably leads to nonunion, progressive deformity, and catastrophic implant failure. In these cases, the loose stem must be extracted, the fracture stabilized, and a longer revision stem inserted that bypasses the most distal fracture line by a minimum of two cortical diameters.

Contraindications to immediate definitive fixation or one-stage revision include the presence of an active periprosthetic joint infection (PJI) or a patient who is medically unstable. If a PJI is identified preoperatively or encountered intraoperatively (evidenced by purulence, positive frozen sections, or elevated synovial markers), the surgeon must pivot to a staged approach. This involves thorough debridement, removal of all hardware, stabilization of the fracture (often with temporary external fixation or antibiotic-impregnated cement spacers spanning the defect), and targeted intravenous antibiotic therapy. Definitive reconstruction is delayed until the infection is definitively eradicated.

Pre-Operative Planning, Templating, and Patient Positioning

Imaging Modalities and Diagnostic Studies

Meticulous preoperative planning is the bedrock of successful periprosthetic fracture management. The investigation begins with high-quality orthogonal radiographs, including an anteroposterior (AP) and lateral view of the entire affected femur, an AP pelvis, and often an AP of the contralateral intact femur for templating purposes. The surgeon must meticulously scrutinize these radiographs to delineate the fracture geometry, assess the degree of comminution, and critically evaluate the stability of the femoral component.

It is paramount to identify any evidence of implant loosening, as this dictates the entire surgical algorithm. Definite radiographic signs of loosening include progressive periprosthetic radiolucency, subsidence of the stem, fracture of the cement mantle, and debonding at the cement-implant interface. Probable signs of loosening include greater than 2 mm of focal lucency, localized endosteal scalloping, and pedestal formation at the tip of the stem. Whenever possible, the surgeon must obtain pre-injury radiographs. Comparing the current position of the stem to its pre-injury baseline is the most sensitive method for detecting subtle subsidence.

Beyond plain radiography, computed tomography (CT) can be an invaluable adjunct, particularly in highly comminuted B1 fractures or when the stability of the stem remains equivocal on plain films. CT with metal artifact reduction sequences (MARS) provides superior visualization of the bone-implant interface and helps map out the available bone stock for screw purchase. Additionally, a thorough laboratory workup is required. Inflammatory markers, including the erythrocyte sedimentation rate (ESR) and C-reactive protein (CRP), should be drawn to rule out indolent infection. While these markers can be elevated secondary to the acute trauma, severe elevations, particularly in the setting of prodromal thigh pain prior to the fall, should raise a high index of suspicion for an underlying periprosthetic joint infection.

Preoperative Templating and Implant Selection

Digital templating is a non-negotiable step in the preoperative workflow. For Vancouver Type B1 and C fractures planned for ORIF, the surgeon must template the length of the plate required. The fundamental rule is to use a plate of sufficient length to span the entire femur, thereby preventing the creation of a new stress riser. The plate should extend proximally to the greater trochanter and distally to the femoral condyles. The surgeon must also template the trajectory of proximal screws, identifying which holes will require cerclage cables, variable-angle locking screws, or unicortical locking screws to safely bypass the intramedullary stem.

For Vancouver Type B2 and B3 fractures, templating is focused on selecting the appropriate revision stem. The revision stem must achieve rigid diaphyseal fixation distal to the most distal fracture line. The standard doctrine dictates that the new stem must bypass the fracture by a minimum of two cortical diameters. Surgeons must template for fluted, tapered, titanium modular stems, which provide excellent rotational stability and axial support in the diaphysis. The modularity allows the surgeon to independently adjust leg length and version after diaphyseal fixation has been achieved.

Patient positioning is dictated by the planned surgical approach and the anticipated need for revision. Most periprosthetic femur fractures are approached with the patient in the lateral decubitus position on a radiolucent flat Jackson table or a standard operating table. This position allows for an extensile direct lateral approach to the entire femur and provides excellent access to the hip joint if revision arthroplasty becomes necessary. Rigid pelvic positioners are utilized, and the entire operative limb is prepped and draped free to allow for dynamic manipulation during fracture reduction. Fluoroscopy must be brought in prior to prepping to ensure unhindered AP and lateral visualization of the entire femur from the hip joint to the knee.

Step-by-Step Surgical Approach and Fixation Technique

Patient Positioning and Surgical Exposure

The surgical approach for managing periprosthetic femur fractures must be extensile, respecting the soft tissue envelope while providing adequate visualization for complex reconstruction. A direct lateral approach is most commonly utilized. The skin incision is made along the lateral aspect of the thigh, extending from the greater trochanter distally toward the lateral femoral condyle as dictated by the fracture pattern. The fascia lata is incised in line with the skin incision.

Once the fascia is opened, the vastus lateralis is encountered. To preserve the critical periosteal blood supply, the muscle is not stripped off the bone. Instead, a subvastus or a vastus-splitting approach is employed. The vastus lateralis can be elevated anteriorly off the lateral intermuscular septum, ligating the perforating branches of the profunda femoris artery as they are encountered. This exposes the lateral femur while maintaining the anterior soft tissue attachments, which are vital for indirect fracture healing.

During the exposure, meticulous care is taken to avoid aggressive periosteal stripping. The fracture hematoma is preserved where possible, and only the bone necessary for plate application and reduction is exposed. If a revision arthroplasty is anticipated (Vancouver B2/B3), the proximal exposure is extended to allow for dislocation of the hip, utilizing the previous surgical interval if feasible, while being mindful of the abductor mechanism.

Reduction Strategies and Biologically Friendly Techniques

Reduction of periprosthetic fractures requires a paradigm shift from traditional absolute stability techniques. Because these fractures typically occur in osteopenic bone and are often comminuted, attempting anatomical reduction of every fragment is not only futile but biologically detrimental. Instead, surgeons must employ indirect reduction techniques to restore the mechanical axis, length, and rotation of the limb.

Traction is applied longitudinally, and large reduction clamps, such as pointed Weber clamps or collinear reduction forceps, are used judiciously. Bumps, sterile tourniquets, or temporary external fixators can be used to assist in holding the reduction. It is critical to avoid placing the limb in varus alignment, as varus malreduction significantly increases the bending moment on the lateral plate, leading to a high rate of hardware failure. The mechanical axis must be restored to a neutral or slightly valgus alignment.

Once provisional reduction is achieved, it is confirmed with biplanar fluoroscopy. The surgeon must verify that the fracture is out of varus, that the leg length is restored relative to the contralateral side (if templated), and that the rotation aligns with the linea aspera posteriorly. Only after satisfactory alignment is confirmed does the definitive fixation process begin.

Fixation Constructs: Lateral Plating, Cables, and Allograft Struts

The fixation of Vancouver Type B1 fractures remains a topic of intense biomechanical and clinical debate, specifically regarding the use of isolated lateral locked plating versus the addition of an anterior cortical allograft strut. Irrespective of the specific philosophy, the foundational construct relies on a robust lateral periprosthetic locking plate. The plate is slid submuscularly along the lateral aspect of the femur.

Proximal fixation around the indwelling stem is the most challenging aspect. The plate must overlap the stem significantly, ideally reaching the tip of the greater trochanter. Fixation here is achieved using a combination of cerclage cables and specialized screws. Cerclage cables are passed carefully using cable passers, ensuring they remain directly on the bone to avoid capturing the sciatic nerve posteriorly or the femoral vessels medially. Modern periprosthetic plates feature offset holes that allow for the insertion of variable-angle locking screws or unicortical locking screws that can safely bypass the implant mantle.

To augment the construct, particularly in cases of severe osteopenia or comminution, an anterior or medial cortical allograft strut can be applied. This creates a "90-90" orthogonal fixation construct. Biomechanical literature heavily supports this configuration, demonstrating superior resistance to torsional and bending forces compared to lateral plating alone. The allograft strut is secured with cerclage cables, effectively increasing the bone mass and providing a biological scaffold for eventual incorporation. Distal to the fracture, standard bicortical locking and non-locking screws are utilized to achieve rigid diaphyseal fixation, adhering to the principle of a long working length to distribute stress.

Managing Loose Implants (Vancouver B2 and B3)

For Vancouver Type B2 and B3 fractures, osteosynthesis alone is doomed to fail. The surgical technique must address both the fracture and the loose implant. The hip is dislocated, and the loose femoral stem is extracted. In B2 fractures, where bone stock is adequate, the fracture site is often used as a surgical window to aid in the removal of the old cement mantle or distal pedestal.

Once the canal is cleared, the fracture is provisionally reduced and held with cerclage cables. A fluted, tapered, titanium revision stem is then sequentially milled and impacted into the intact diaphysis distal to the fracture. The flutes provide rotational stability, while the taper engages the cortical bone for axial support. The stem must bypass the most distal fracture line by at least two cortical diameters.

In Vancouver B3 fractures, the proximal bone stock is so severely compromised that it cannot support a standard revision stem. These cases require highly complex reconstructions. Options include the use of a tumor prosthesis (proximal femoral replacement), which bypasses the deficient bone entirely, or an impaction grafting technique combined with a long stem and massive structural allografts (allograft-prosthesis composite). These procedures are technically demanding and carry higher rates of complications, but they are necessary salvage operations to restore ambulation in patients with catastrophic bone loss.

Complications, Incidence Rates, and Salvage Management

Despite meticulous surgical technique and modern implants, the complication rate following periprosthetic femur fracture surgery remains distressingly high. The compromised host physiology, poor bone quality, and altered biomechanics create a hostile environment for healing. Surgeons must be hyper-vigilant in monitoring for these complications and possess the technical armamentarium to execute salvage procedures when necessary.

Nonunion and construct failure are among the most dreaded mechanical complications. Failure often occurs due to technical errors, such as utilizing a plate that is too short, failing to achieve adequate proximal overlap of the stem, or malreducing the fracture into varus. Varus collapse places immense tensile stress on the lateral plate, inevitably leading to fatigue failure of the hardware. When aseptic nonunion or hardware failure occurs, salvage management typically involves revision osteosynthesis with a longer, more robust construct, the addition of structural allograft struts, and the application of autologous bone graft or orthobiologics to stimulate the biological healing response.
